This is the upper part of a teaching skeleton.

Pictures taken with D5300 and Nikkor 35mm

Human skull and neck

# 土木学会選奨土木遺産　万世大路(二ツ小屋隧道)
# Japan Society of Civil Engineers Heritage
The road which connects Fukushima city, Fukushima prefecture to Yonezawa city, Yamagata prefecture was opened in 1881(明治14年) and named after “Banseitairo  Road” by the Emperor Meiji.Futatsugoya Tunnel is one of the two tunnels which are located in Banseitairo  Road. It was taken expansion work to motor vehicles can go through in 1934(昭和9年). In 1966(昭和41年), an another tunnel was opened at new place to they can go through if it has heavy snow and Banseitairo Road became the “Abandoned road” after finished its role.

![Image from Gyazo](https://i.gyazo.com/6fee71412c237d0e8fdfa281128ac31a.jpg)


3D digitizing methods : Photogrammetry
Software : Reality Capture
Equipment : Nikon D750,NIKKOR 16-35mm f/4G,SB-910
Images:  1916 photos
Date : Apr. 2020

Futatsugoya Tunnel “Abandoned road” japan

Raw scan made on cinema movie projector that is standing in Kijów Centrum Cimena in Kraków, Poland
It was used for 35mm tape. Produced in the 1961 by Łódzkie Zakłady Kinotechniczne in Poland. The projector was designed for cinemas with rooms up to 1000 seats. It was then one of the most popular models used in Polish cinemas

The projector was equipped with an aspherical mirror with a diameter of 356 mm and a focal length of 120 mm. The standard lens provided by the manufacturer was Polkinar 1.8 / 100

The basic equipment of the projector was an optical sound reading system with two exposure bulbs - one in the working position, the other one in reserve (both fixed in the rotating holder, which allowed for exchange without interrupting the projection). In addition, the projector could be equipped with a 4-channel magnetic sound pickup

The projector was powered by a three-phase asynchronous motor. The engine was started using an automatic starter.
https://youtu.be/-xr1BMyKNWI
MusicInfo: Piano by AShamaluevMusic

Cinema Movie Projector AP5 - 1961

- Captured using Sony a9 w/ Voigtlander 15mm lens.
- Reconstructed with RealityCapture
- Cleaned up w/ MeshMixer

Elevator in Berlin - Realities.io

A 40+ years old Male hand.

Pictures taken with D5300 + Nikkor 35mm

Male Hand

97 Shots - Panasonic GF7

25mm (50mm equivalent)  // F6.3 //  200iso

Processed with agisoft photoscan

Little bridge found in a botanic park in britanny - France - Very cute japanese garden scenery I had to try to take the atmosphere of the scene.. not that easy, the weather wasn't that good and lightning tricky. Not enough pics of the under part. 8k textures / I tried to not make a mesh too big.

I hope you will like it

Bridge and Japanese garden

An 18th century bronze statue believed to be of the Roman Emperor Trajan (mistakenly referred to as Julius Ceasar by several excited tourists who stopped for a selfie opportunity, and did not read the plaque).  it is situated next to a section of the London Wall near of the Tower Hill underground station.

Better photography focussing on the whole right arm and left hand would most likely have produced a better end result.


Model was created from 269 photos (probably could of taken more) shot with a Nikon D5300 (using a 18-55mm kit lens) and aligned on High in Agisoft (using medium level dense cloud).

Plaque Reads:

STATUE BELIEVED TO BE OF THE ROMAN EMPEROR TRAJAN / A.D. 98–117

IMPERATOR CAESAR NERVA TRAJANUS AUGUSTUS

PRESENTED BY THE TOWER HILL IMPROVEMENT TRUST AT THE

REQUEST OF THE REVEREND P.B. CLAYTON , CH.MC.DD.

FOUNDER PADRE OF TOC H

Statue of Emperor Trajan (Tower Hill, London)

Here you can see it in action:
https://youtu.be/9Cofmy4bZX4

Uh...didn't find a way to attach a package with .stl files. Here they are:
https://drive.google.com/open?id=1hNs4ZOr_H-nXIlVeMiUy7iY9UJ5GkodB

Made with Fusion 360. A toy car with double-acting 1-cylinder compressed air engine (like the steam locomotives have). Has steering, which even works. I call it "vapemobile" because of the remote shape).

Apart from these printed parts, you'll need some extra ones to assemble it:

* 623ZZ bearing (4x10mm, 3mm hole) (may poorly work without it)
* Piece of 1.75mm filament
* Rubber band
* Thin plastic bag
* 6mm silicon pipe (can be found in any aquarium shop)
* 4mm pipe from intravenous dropper (or any that you could pull onto the syringe end)
* Two 2ml syringes
* 8mm piece of 4mm PTFE tube (optional)
* Air balloon
* Bolts: M3x6 x8, M3x8 x8, M3x10 x3, M3x12 x5, M3x14, M3x25, M3x50
* M3 washers x10
* M3 nuts x30

3d Printable Pneumatic-Engined Toy Car

This house fly (approx. 5mm) was scanned with DISC3D: https://zookeys.pensoft.net/article/24584/

Musca domestica

The Borchardt C-93 (Construktion 93) pistol was designed by Hugo Borchardt (1844–1921) in 1893. Ludwig Loewe & Company of Berlin, Germany, a manufacturer of machine tools, produced the C-93, a semi-automatic pistol that he had invented based upon the Maxim toggle-bolt design. Borchardt also developed the high-velocity bottlenecked 7.65×25mm Borchardt cartridge for the C-93. Borchardt's assistant at the time, Georg Luger, also claimed to have influenced its design. With over 3,000 manufactured by Loewe and Deutsche Waffen und Munitionsfabriken, Borchardt C-93 was the first mass-produced semi-automatic pistol.

Borchardt C93

# About:
Another gun-porn still life featuring a customized M249 SAW, displayed with a set of specialized 5.56×45mm NATO cartridges.
<hr>

  *Іnscription on the ammo box:*
>
> *"There are people who bring joy.
> There are people who bring pain.
> And then there's me, I bring a machine gun."*
<hr>
# Related:
* [**M249 SAW scene (1)**](https://sketchfab.com/3d-models/m249-saw-scene-1-fbab0e48119f47e6882f531ccbc8c074)
* [**M249 SAW (classic)**](https://sketchfab.com/3d-models/m249-saw-scene-1-fbab0e48119f47e6882f531ccbc8c074)
* [**FN Minimi kit**](https://sketchfab.com/3d-models/fn-minimi-kit-891ff4510dc6490fa3a0ab862f61c435)
# [**Ammunition collection**](https://sketchfab.com/leondp/collections/ammunition-e73c6f144c624fee8d93bc2be3d2873f)
<hr>
# Used Software:
* Blender (4.1.1)
* Substance 3D Painter

M249 "SAW" Custom Set + Ammo Pack

Male Spotted Lanternfly specimen. 45mm max width. Ground resolution, 13μm/pix, RMS reproduction error 0.767606 pix. Specimen collected by Dr. John Cooley, 9/9/2025, CT Hartford County, UConn Campus Hartford.

Spotted Lanternfly Male 001

Repositorio de modelos 3D de Ddiaz Design

![](https://www.corazon-world.com/wp-content/uploads/2021/08/VAP1.jpg)

With the concept of " letting people fully enjoy the WRX" and the desire to boldly customize the VA-WRX even further, CORAZON have created the "Sportire Wide Body Kit," an overfender kit that widens the front by approximately 60mm on each side and the rear by approximately 75mm on each side, based on the design concept of "Neo Classic," and venturing into the realm of customization that no one else can venture into.

Instagram del proyecto: https://www.instagram.com/ddiaz.design/

Paypal Donations: https://paypal.me/sergiodd

Based on a CSR2 3d model

2020 CORAZON WRX SPORTIRE WIDE BODY KIT

## Scanning
The motorcycle was scanned in IR-mode on the Rigil using 1.5mm resolution and feature tracking without connection to a PC. The picture of the bike misleads about the lighting conditions (modern smartphone witchery be thanked): the place was too dim for texture tracking and in these cases better results can be achieved by only using feature tracking. For scanning itself I didn't do any preparations like scan spray and focused on the both sides by using the saddle as the connection for switching sides.
While scanning the Rigil held a constant 20 FPS (if texture tracking would be also enabled for hybrid tracking FPS will be lower). Scanning itself took roughly 5min.

## Post-Processing
Post processing was done on my workstation and included generation of the point cloud and subsequent meshing in recommended settings. Since it came out to 15M triangles I reduced it to 4M so the scan could be uploaded to Sketchfab.

Honda Motorcycle - Einscan Rigil IR Scan

New *FN SCAR L* genereation. 16S or *Gen 3*. The main differences are the M-Lok handguard, ambidextrous controls and buffered bolt carrier. *5.56x45mm NATO, Short stroke piston.*

190226: fix rail triangulation

low-poly SACR 16S

*MP5* **K** (**K**urz - *Short*) - shortenned version of MP5 submachine gun. *Barrel lenght = 115mm. 9x19mm Parabellum, Roller-delayed blowback.*

low-poly HK MP5K

## Scanning
Scanning was done at 2mm target resolution and no scan spray was used. I was to lazy to calibrate the Trackit so some of the surface quality defects may be accountable to this problem. Tracking quality was indicated as poor so time to calibrate. Scan was performed in three parts (could have been two but the first placement of the tracker was suboptimal) and each scan consists of paint brush movements until full data quality was reached.

## Post-Processing
Processing work was minimal by first fusing at 1mm (software even recommended 0.75mm) and then aligning the partial scans to one whole scan. Meshing was done at recommended settings and alignment to the coordinate system with Quicksurface.

Tiled Stove - Revopoint Trackit

## Scanning
Scanning was done in sPC connected mode (WiFi, with latest update 120FPS speed) at a moderate high point distance of 0.15mm (can go up/down to 0.05mm but at 0.15mm it already resulted in a 20M triangle file...) until target quality was reached. Keep an eye on ideal scan distance since it reduces with increasing point distance. When you are too far away scanning will be drastically slower compared to when you're in the ideal distance.

## Post-Processing
When finishing the single scans it already creates a point cloud so I only had to align using automatic feature alignment (after deleting all unnecessary data from around the object). Afterwards I used Quicksurface to align the scan to the coordinate system and reduce the triangle count to a manageable 4M triangles.

Wax Statue Virgin Mary - Einscan Rigil

## Scanning
Scanning was done in PC connected mode (WiFi, with latest update 120FPS speed) at a moderate high point distance of 0.15mm (can go up/down to 0.05mm but at 0.15mm it already resulted in a 20M triangle file...) until target quality was reached.
I placed the casting on bed of marker cards and geometries so I can also capture the sides of the casting which I also use for aligning the two scans I created (top and bottom). The scan itself was performed with both cross and parallel line mode taking roughly 5min for scanning. No scan spray was used for scanning.

## Post-Processing
When finishing the single scans it already creates a point cloud so I only had to align using automatic feature alignment (after deleting all unnecessary data from around the object). Afterwards I used Quicksurface to align the scan to the coordinate system and reduce the triangle count to a manageable 4M triangles.

Wax Casting Traditional Scene - Einscan Rigil

## Scanning
Three scans were done, all in the same setting: Owl placed on turntable with markers around it, marker tracking used and exposure set to ensure no under- or overexposure. All scans were taken until full data quality was reached.
Scans:
- 0.2mm IR small mode (highest resolution selectable), texture capture enabled
- 0.1mm laser mode, texture capture enabled
- 0.05mm laser mode (high detail capture of the face area, whole bird in 0.05 would result in unusable large scan)

## Post-Processing
No special post-processing was done, only meshing at default settings within Exstar Hub and performing texture optimization.

Wooden Owl Laser 0.1mm - Einstar Rockit

## Scanning
Scanning was done in PC connected mode (WiFi, with latest update 120FPS speed) at a moderate high point distance of 0.15mm (can go up/down to 0.05mm but at 0.15mm it already resulted in a 15M triangle file...) until target quality was reached. Keep an eye on ideal scan distance since it reduces with increasing point distance.
I placed the statue on bed of marker cards and geometries so I can also capture the sides of the statue which I also use for aligning the two scans I created (top and bottom). The scan itself was performed with both cross and parallel line mode taking roughly 5min for scanning. No scan spray was used for scanning.

## Post-Processing
When finishing the single scans it already creates a point cloud so I only had to align using automatic feature alignment (after deleting all unnecessary data from around the object). Afterwards I used Quicksurface to align the scan to the coordinate system and reduce the triangle count to a manageable 4M triangles.

Wood Statue Boy with Dog - Einscan Rigil

Wooden Owl Laser 0.05mm - Einstar Rockit

## Scanning
The scans were captured with wireless connection to my workstation to capture the data faster (with latest update laser mode now reaches 120FPS over WiFi, not bad at all).
For IR mode I chose large mode at 0.5mm resolution and marker tracking as well as small mode at 0.2mm resolution with marker tracking. Normally I don't use small mode much since I mainly use markerless laser scanning for parts where I would use it normally. My sweet spot for IR mode is somewhere between 0.5mm and 3mm.

## Post-Processing
For all three scans precessing was done using the recommended settings within ExScan Rigil. This includes point cloud generation and meshing.
After exporting the meshes I used Quicksurface to align the meshes to the coordinate system and each other. The laser scans had to be reduced to allow upload to Sketchfab (just under 4M triangles will result in a 100MB ply when exporting from Quicksurface).

Scan Bench - Einscan Rigil IR Large

The ZTZ-99 (Type 99) is China’s first mass-produced third-generation main battle tank (MBT), developed by Norinco to modernize the PLA's armored forces. It features a 125mm smoothbore gun with an autoloader, advanced composite/ERA armor, and a 1,500hp engine in later variants. It is considered comparable to Western tanks like the M1 Abrams.
