## Scanning
Scanning was done in sPC connected mode (WiFi, with latest update 120FPS speed) at a moderate high point distance of 0.15mm (can go up/down to 0.05mm but at 0.15mm it already resulted in a 20M triangle file...) until target quality was reached. Keep an eye on ideal scan distance since it reduces with increasing point distance. When you are too far away scanning will be drastically slower compared to when you're in the ideal distance.

## Post-Processing
When finishing the single scans it already creates a point cloud so I only had to align using automatic feature alignment (after deleting all unnecessary data from around the object). Afterwards I used Quicksurface to align the scan to the coordinate system and reduce the triangle count to a manageable 4M triangles.

Wax Statue Virgin Mary - Einscan Rigil

## Scanning
Scanning was done in PC connected mode (WiFi, with latest update 120FPS speed) at a moderate high point distance of 0.15mm (can go up/down to 0.05mm but at 0.15mm it already resulted in a 20M triangle file...) until target quality was reached.
I placed the casting on bed of marker cards and geometries so I can also capture the sides of the casting which I also use for aligning the two scans I created (top and bottom). The scan itself was performed with both cross and parallel line mode taking roughly 5min for scanning. No scan spray was used for scanning.

## Post-Processing
When finishing the single scans it already creates a point cloud so I only had to align using automatic feature alignment (after deleting all unnecessary data from around the object). Afterwards I used Quicksurface to align the scan to the coordinate system and reduce the triangle count to a manageable 4M triangles.

Wax Casting Traditional Scene - Einscan Rigil

## Scanning
Scanning was done in PC connected mode (WiFi, with latest update 120FPS speed) at a moderate high point distance of 0.15mm (can go up/down to 0.05mm but at 0.15mm it already resulted in a 15M triangle file...) until target quality was reached. Keep an eye on ideal scan distance since it reduces with increasing point distance.
I placed the statue on bed of marker cards and geometries so I can also capture the sides of the statue which I also use for aligning the two scans I created (top and bottom). The scan itself was performed with both cross and parallel line mode taking roughly 5min for scanning. No scan spray was used for scanning.

## Post-Processing
When finishing the single scans it already creates a point cloud so I only had to align using automatic feature alignment (after deleting all unnecessary data from around the object). Afterwards I used Quicksurface to align the scan to the coordinate system and reduce the triangle count to a manageable 4M triangles.

Wood Statue Boy with Dog - Einscan Rigil

## Scanning
The scans were captured with wireless connection to my workstation to capture the data faster (~80FPS over WiFi).
For the laser scan marker tracking was used. The scan bench was placed on a turntable with marker geometries placed around it to allow scanning from shallower angles (as seen in last picture). The resolution was set to 0.1mm and exposure was adjusted so the white print wasn't overexposed. For laser mode I used a combination of cross, parallel and single line mode, changing them can be done by double pressing the scan start button on the scanner.

## Post-Processing
For both scans processing was done using the recommended settings within CrealityScan. This is basically only Fusion since it already generates a mesh at this step which can directly be exported.
After exporting the meshes I used Quicksurface to align the meshes to the coordinate system and each other.

Scan Bench - Creality Sermoon P1 Laser

## Scanning
The scans were captured with wireless connection to my workstation to capture the data faster (with latest update laser mode now reaches 120FPS over WiFi, not bad at all).
For the laser scan marker tracking was used. The scan bench was placed on a turntable with marker geometries placed around it to allow scanning from shallower angles (as seen in last picture). The resolution was set to 0.1mm and exposure was adjusted so the white print wasn't overexposed. For laser mode I used a combination of parallel and cross line laser mode, changing them by using the scanners touch screen while scanning.

## Post-Processing
For all three scans precessing was done using the recommended settings within ExScan Rigil. This includes point cloud generation and meshing.
After exporting the meshes I used Quicksurface to align the meshes to the coordinate system and each other. The laser scans had to be reduced to allow upload to Sketchfab.

Scan Bench - Einscan Rigil Laser

## Scanning
The scans were captured with wireless connection to my workstation to capture the data faster (with latest update laser mode now reaches 120FPS over WiFi, not bad at all).
For IR mode I chose large mode at 0.5mm resolution and marker tracking as well as small mode at 0.2mm resolution with marker tracking. Normally I don't use small mode much since I mainly use markerless laser scanning for parts where I would use it normally. My sweet spot for IR mode is somewhere between 0.5mm and 3mm.

## Post-Processing
For all three scans precessing was done using the recommended settings within ExScan Rigil. This includes point cloud generation and meshing.
After exporting the meshes I used Quicksurface to align the meshes to the coordinate system and each other. The laser scans had to be reduced to allow upload to Sketchfab (just under 4M triangles will result in a 100MB ply when exporting from Quicksurface).

Scan Bench - Einscan Rigil IR Large

## Scanning
Scanning was done in PC connected mode (WiFi, with latest update 120FPS speed) at a moderate high point distance of 0.15mm (can go up/down to 0.05mm but at 0.15mm it already resulted in a 15M triangle file...) until target quality was reache
I placed the statue on bed of marker cards and geometries so I can also capture the sides of the statue which I also use for aligning the two scans I created (top and bottom). The scan itself was performed with both cross and parallel line mode taking roughly 5min for scanning. No scan spray was used for scanning.

## Post-Processing
When finishing the single scans it already creates a point cloud so I only had to align using automatic feature alignment (after deleting all unnecessary data from around the object). Afterwards I used Quicksurface to align the scan to the coordinate system and reduce the triangle count to a manageable 4M triangles.

Wood Statue of Bird Nest - Einscan Rigil

## Scanning
The scans were captured with wireless connection to my workstation to capture the data faster (with latest update laser mode now reaches 120FPS over WiFi, not bad at all).
For IR mode I chose large mode at 0.5mm resolution and marker tracking as well as small mode at 0.2mm resolution with marker tracking. Normally I don't use small mode much since I mainly use markerless laser scanning for parts where I would use it normally. My sweet spot for IR mode is somewhere between 0.5mm and 3mm.

## Post-Processing
For all three scans precessing was done using the recommended settings within ExScan Rigil. This includes point cloud generation and meshing.
After exporting the meshes I used Quicksurface to align the meshes to the coordinate system and each other.

Scan Bench - Einscan Rigil IR Small

## Scanning
Scanning was done in sPC connected mode (WiFi, with latest update 120FPS speed) at a moderate high point distance of 0.15mm (can go up/down to 0.05mm but at 0.15mm it already resulted in a 20M triangle file...) until target quality was reached.
I placed the casting on bed of marker cards and geometries so I can also capture the sides of the casting which I also use for aligning the two scans I created (top and bottom). The scan itself was performed with both cross and parallel line mode taking roughly 5min for scanning. No scan spray was used for scanning.

## Post-Processing
When finishing the single scans it already creates a point cloud so I only had to align using automatic feature alignment (after deleting all unnecessary data from around the object). Afterwards I used Quicksurface to align the scan to the coordinate system and reduce the triangle count to a manageable 4M triangles.

Wax Portrait Virgin Mary - Einscan Rigil

## Scanning
The scans were captured with wireless connection to my workstation to capture the data faster (~80FPS over WiFi).
IR mode had to be done in feature tracking since marker tracking is not yet supported by the software. For this I used the normal size which provides better tracking and is the mode I use most often when using IR mode (same mode was selected with the Rigil in IR mode).

## Post-Processing
For both scans processing was done using the recommended settings within CrealityScan. This is basically only Fusion since it already generates a mesh at this step which can directly be exported.
After exporting the meshes I used Quicksurface to align the meshes to the coordinate system and each other. The laser scans had to be reduced to allow upload to Sketchfab (just under 4M triangles will result in a 100MB ply when exporting from Quicksurface).

Scan Bench - Creality Sermoon P1 IR Normal
